Pyroplast White Intumescent Paint

PRODUCT DESCRIPTION

Pyroplast Wood P forms a carbon char when affected by heat as it uses a water based fire protection coating intended for internal use.

Coverage = 14.3m2 per 5kg (This allows for 2 coats)

Pyroplast Wood P slows the combustion of both natural and composite woods, providing fire retardancy protection.

Pyroplast Wood P emphasizes the interior design of timber structures and therefore is an attractive option to architects, builders and end-users.

USES

Lessens the combustibility of hard- and softwood > 10 mm thickness and other timber by-products, such as plywood, chipboard, fibre insulation board, hardboard and also on veneering > 13 mm thickness.

Shields against heat, checks fire, restricts the generation of fire and spread of flame and reduces flue-gas temperatures.

Pyroplast Wood P should not be used in areas of high humidity, heat sources or on surfaces where significant physical impact is likely.

PROPERTIES

Water based coating system

VOC Pyroplast Wood P: 0 g/l

VOC Pyroplast Top W: approx. 48 g/l

Free of Halogens and aromatic solvents

Low material consumption

Simple application

No additional statical load of coating

Individual coloration possible with topcoat Silka Pyroplast Top W

TESTS

Approval/Standards

Pyroplast Wood P is classified to many standards worldwide including EN 13501-1, Bs1d0.

PRODUCT DATA

Colour Shades:

Pyroplast Wood P: white, black on inquiry

Pyroplast Top W: White, available in all RAL colours on request

Packaging:

Pyroplast Wood P: 5 kg and 25 kg, net weight

Pyroplast Top W: 3 l and 11 kg, net weight

Imdg-Code-No Not applicable

SHELF LIFE 18 months, in cool and dry storage conditions and original unopened containers.

Expiry date is noted on the label of each tin.

Protect against frost.

TECHNICAL DATA

Mass Density:

Pyroplast Wood P:  approx. 1.29 g/cm3 at 20° C

Pyroplast Top W:  approx. 1.26 g/cm3 at 20° C

Solids By Weight:

Pyroplast Wood P:  approx. 65% (according to EN ISO 3251)

Pyroplast Top P:  approx. 52% (according to EN ISO 3251)

Flash Point:

Pyroplast Wood P: not applicable

Pyroplast Top W:  not applicable

Material Consumption:

• 1 x120g/m2 Pyroplast Wood P Primer (if necessary)
• 1 x>350g/m2 Pyroplast Wood P

plus

• 1 x120g/m2 Pyroplast Top W

These consumption rates refer to the classification acc. to  EN 13501-1, Bs1d0

B   EN 13823 FIGRA ≤ 120 W/s and LFS  < edge of specimen and THR600s ≤ 7,5 MJ

and

EN ISO 11925-2 Exposure = 30s Fs < 150mm within 60 s

s1   SMOGRA ≤ 30 m2 / s2 und TSP 600s ≤ 50 m2

d0 No flaming droplets/particles in EN 13823 with 600 s;

Not suitable for use on all woods. Please contact us for more details.

APPLICATION

Coating Systems:

Primer (if necessary), Pyroplast Wood P Primer

Intumescent coating, Pyroplast Wood P

Topcoat, Pyroplast Top W

Surface Preparation:

Substrate must be dry, free from dust, oil, wax, grease, dirt, resin, etc; Existing coatings with poor adhesion have to be completely removed, e.g. with solvent-based paint stripper or to be rubbed down. Surfaces that have been treated with non-acid resistant coatings or release agents such as emulsion paints containing lime, chalk or lithopone should be rubbed down completely. Timber substrates with wetting difficulties should be roughened thoroughly with abrasive paper.

Pre-Treatment with Wood Preservatives:

If resistance to wet rot, fungi or insect attack is requested, we recommend using commercial preservative agents based on oil alkyd resins provided they are compatible with the Pyroplast fire protection system. Apply Pyroplast fire protection coating system only after the preservative treatment is completely dry. The moisture content of the timber should be below 15%. Pyroplast Wood P Primer may be used to allow sufficient adhesion or avoid diffusion of wood ingredients on resinous wood.

Preparation of Material:

Stir thoroughly, free of lumps.

The method of application has a major effect on achieving uniform thickness and appearance. Spray application will give the best results. The indicated dry film thickness is easily achieved by airless spray. In case of an application by roller or brush, additional layers may become necessary to achieve the required coating thickness, depending on type of construction, site conditions, colour shade etc. Prior to application, a trial on site may be useful to ensure that the selected application method will provide the requested results.

Airless Spraying:

• Material shall be applied undiluted
• Airless spray equipment with pressure ratio ≥ 30:1
• Filters should be removed
• Hose diameter not below 3/8 “
• Whipline 1.5 – 2 m, NW 6, may be used

Recommended nozzle sizes for each product are as follows:

• Pyroplast Wood P Primer: 0.27 – 0.34 mm or 0.011 – 0.017 “
• Pyroplast Wood P: 0.34 – 0.64 mm or 0.017 – 0.025 “
• Pyroplast Top W: 0.27 – 0.56 mm or 0.011 – 0.023 “

Above data shall be used as a guideline with variations being made to suit local conditions.

Brushing and Rolling:

• Material shall be applied in supply viscosity
• Load natural fine bristle brushes or short pile lambswool rollers are recommended

Application Conditions:

Pyroplast Wood P Primer, Pyroplast Wood P and

Pyroplast Top W: Object temperature not below + 10° C, to max. +40° C*

Relative humidity max. 80%

Application temperature shall be at least > 3 K above dew point.

In case relative humidity exceeds 80% special measures must be taken to prevent the condensation forming while application.

At high moisture content of the timber (>15%), the coating is unlikely to dry satisfactorily and blooming may result. Therefore the moisture content of the timber should be, as near as possible to the level it will stabilise at in use.

*If higher temperatures occur, please consult the Technical department for further assistance.

DRYING/CURING

At approx. + 20° C temperature and 60% relative humidity.

Pyroplast Wood P Primer:

• Touch dry: after approx. 3 hours.
• Overcoating: after approx. 6-8 hours.

Pyroplast Wood P:

• Touch dry: after approx. 6 hours.
• Overcoating: after approx. 48 hours with Pyroplast Top W.

Pyroplast Top W:

• Touch dry: after approx. 2 hours.
• Fully dry: after approx. 24 hours.

Different temperature and relative humidity’s have an influence on drying time.

Ensure that the previous coat is being fully dry, prior overcoating is carried out.

CLEANING OF EQUIPMENT

Immediately after use with water.

IMPORTANT NOTICE

EU-Directive 2004/42/EC (Decopaint-Directive)

The maximum allowed VOC content acc. to EU-Directive 2004/42/EC (product class IIA / g, type Wb) in the ready for use material is 30 g/l (limit 2010).

The maximum VOC content of Pyroplast Wood P Primer is 20 g/l VOC.

The maximum allowed VOC content acc. to EU-Directive 2004/42/EC (product class IIA / i, type Wb) in the ready for use material is 140 g/l (limit 2010).

The maximum VOC content of Pyroplast Wood P is 0 g/l VOC.

The maximum allowed VOC content acc. to EU-Directive 2004/42/EC (product class IIA / i, type Wb) in the ready for use material is 130 g/l (limit 2010).

The maximum VOC content of Pyroplast Top W is < 48 g/l VOC.

Value Base

All technical data stated in this description are based on laboratory tests. Actual measured data may vary due to circumstances beyond our control.

Local Restrictions

Please note that as a result of specific local regulations the performance of this product may vary from country to country. Please consult the local Product Data Sheet for the exact description of the application fields.

Health and Safety Information

Information on the safe handling of chemical products, as well as the essential physical, safety-related, toxicological and ecological data can be found in the current safety data sheets. Observe all relevant regulations, e.g. the hazardous substances act.
