Protecta Service Transit has been designed to maintain the fire resistance of walls and floors when these are breached by continuous cables and plastic pipes.
It is made up of a circular high temperature plastic tube containing a graphite based intumescent lining material which expands upon heating to seal spaces or voids around cables and pipes, thus preventing the passage of flames, smoke and gases.
Available in the following sizes: Ø40 x 150mm, Ø63 x 150mm, Ø90 x 150mm, Ø110 x 150mm, Ø40 x 250mm, Ø63 x 250mm, Ø90 x 250mm, Ø110 x 250mm, Ø40 x 400mm, Ø63 x 400mm, Ø90 x 400mm and Ø110 x 400mm
KEY FEATURES
- Safe, easy and quick to fire stop service penetrations
- Ideal for installations where it is likely that services will be inserted or replaced in the future
- Ideal for installations in tight spaces where it will be difficult to install a normal fire seal at a later stage in the building construction
- A plug in the middle prevents penetration of cold smoke
- New patented fast expanding graphite material
- For cables, plastic pipes and cables inside plastic pipes (conduits)
- Classified for fire sealing all types of constructions; drywalls, masonry or concrete walls and concrete floors
- Can be fitted several ways; cast in concrete, friction fitted in concrete, masonry or gypsum, or inserted in larger apertures with Protecta FR Acrylic, FR Board and EX Mortar
- Very high fire classifications up to 240 minutes for both integrity and insulation
- Certified for PVC-U, PVC-C, PE, LDPE, MDPE, HDPE, ABS, SAN+PVC and PP pipes plus all kinds of cables up to a certain diameter
- No emissions – environmentally and user friendly
- Unlimited storage time (under correct conditions)
- 30 years working life guarantee
